6063 aluminum alloy is widely used in the construction of aluminum doors and windows, curtain wall frame, in order to ensure high wind pressure resistance, assembly performance, corrosion resistance and decorative performance of doors, windows and curtain walls, the comprehensive performance requirements of aluminum alloy profiles are much higher than industrial Profile standard.
Introduction of forged aluminum 6063 aluminum plate
6063 aluminum alloy is widely used in the construction of aluminum doors and windows, curtain wall frame, in order to ensure high wind pressure resistance, assembly performance, corrosion resistance and decorative performance of doors, windows and curtain walls, the comprehensive performance requirements of aluminum alloy profiles are much higher than industrial Profile standard. In the range of 6063 aluminum alloys specified in the national standard GB/T3190, the chemical composition values ââare different, and different material properties are obtained.
When the range is large, the difference in performance fluctuates over a wide range, so that the overall performance of the profile cannot be controlled. Therefore, it is preferred that the chemical composition of 6063 aluminum alloy is the most important part of producing high-quality aluminum alloy building profiles.
Forged aluminum plate 6063 product use and composition
The main alloying elements in the 6063 alloy forged aluminum sheet are magnesium and silicon, which have excellent processing properties, excellent weldability, extrudability and electroplating properties, good corrosion resistance, toughness, easy polishing, over cladding, anodizing It has excellent effect and is a typical extruded alloy. It is widely used in building profiles, irrigation pipes, pipes, rods and profiles for vehicles, benches, furniture, lifts, fences, etc.
Forged aluminum 6063 aluminum sheet chemical composition
The main chemical components are:
Cu; 0.1-, Si; 0.2-0.6-, Fe; 0.35-, Mn; 0.1-, Mg; 0.45-0.9-, Zn; 0.1-, Cr; 0.1-, Ti;
Mechanical properties and analysis of forged aluminum 6063
Tensile strength σb (MPa): 130ï½230 6063 The ultimate tensile strength is 124 MPa Tensile yield strength 55.2 MPa Elongation 25.0 % Elasticity coefficient 68.9 GPa
Forged aluminum 6063 size and size, hardness
1200*2500 HRB95-110
